Specifications

Balanced weave belts

Description

As a specialist in balanced weave conveyor belts, we at Twentebelt understand that choosing the right conveyor belt is crucial for the efficiency and reliability of your production processes. Our balanced weave belts are designed to withstand the most demanding applications and they offer numerous designs and options.

Balanced weave belts, also referred to as spiral woven belts or spiral wirelink belts, can be used for a virtually infinite number of applications. We offer various balanced weave conveyor belts, each with its own unique features to meet your specific requirements. Ranging from super strong for conveying heavy loads over large widths or conveying very hot products to very dense weaves for small products, unsorted goods or products requiring stable support.

Advantages of balanced weave conveyor belts

Many configuration options
From an open structure for maximum airflow to a dense structure for the transfer of small products, we manufacture conveyor belts according on your specific needs.

Excellent heat transfer
Suitable for both light and heavy-duty applications, whilst maintaining the efficiency of your production process.

Small transfer radius
For perfect product transfer, even with complex production configurations.

Belt features

Endless possibilities with balanced weave conveyor belts
Our balanced weave belts offer a virtually endless number of designs and applications. Whether you need extremely high-performance balanced weave belts for heavy loads across large widths and very high temperatures, or you need very densely woven belts for small, delicate products and bulk materials, we offer the solution. Thanks to excellent heat transfer and the capacity for both light and heavy-duty applications, our balanced weave conveyor belts are the perfect choice for various processes and industries.

Focus on food safety
At Twentebelt, the emphasis is on food safety. Our balanced weave belts are manufactured in accordance with the latest food safety standards, guaranteeing a belt that is optimally suited to the most demanding applications in food processing.

Reliable conveyor belts for various industries
Our spiral braided belts are manufactured with the utmost precision and meet the strictest food safety standards, including FDA, GMP and 1935/2004/EC. This makes them ideal for use in food processing applications such as baking, frying, drying, cooling and freezing. In addition, they are perfect for use in tunnel ovens, where consistent performance is essential.

Suitable for the most complex applications
At Twentebelt, we are convinced no application is too complex for our balanced weave conveyor belts. Our wide spiral wire belts with pressed wire offer a perfectly round finish, even with a small radius, guaranteeing optimal product transfer to the next step of your process.

Belt types

GS – Corrugated wirelink conveyor belt

RS – Straight wirelink conveyor belt

CB – ‘Compound’ conveyor belt

SP – Balanced weave belt woven on one side

Side finishing / belt options

Side finishing

Looped edges

Welded edges

Fitted with chain

Belt options

Flights

Edge plates

Belt specification

GS-LK 9,5 – 10 – 2 – 2,8

GS – Corrugated wirelink (alternately woven left and right for a straight run)
LK – Welded edges side finishing
9,5 – Lateral pitch (in mm)
10 – Spiral pitch (in mm)
2 – Wire diameter (in mm)
2,8 – Cross rod diameter (in mm)

Drive

The belt is driven by friction rollers over the entire width of the belt or positively with sprockts in the case of GS belts. The drive is perfectly suited to the application and belt used.

Downloads

Spiral woven belts brochure

English

Spiral woven belt quotation form

English

Multiple Twentebelt colleagues discussing a drawing

A dedicated partner

Our dedication to metal conveyor belts has resulted in high-quality steel belts with a long lifespan. We focus primarily on machine builders in the food industry for whom we manufacture customised conveyor belts. Our services go beyond just supply; we assist and support our clients during both the design and commissioning.

At Twentebelt, we strive to be your reliable partner by applying our experience and expertise to offer the best solutions for your transfer requirements. Contact us today to find out how we can help you with our high-quality, customised metal conveyor belts.

Our approach

Our other belts

Eyelink belts

Our eyelink conveyor belts are robust, versatile, and suitable for numerous food processing applications. They are resistant to high temperatures and corrosive environments, making them ideal for harsh production conditions. In addition, eye-link conveyor belts are flexible in design and durable in use.

Wire mesh belts

Wire mesh conveyor belts are exceptionally efficient, both in terms of applications and specifications. Due to their open structure, they are very suitable for light products and applications where the product needs to have the smallest contact area with the conveyor belt as possible.

TwenteFlex spiral belts

TwenteFlex is our spiral conveyor belt with a unique design without welded connections. The smart design ensures less downtime and eliminates several major causes of conveyor belt problems. TwenteFlex is used worldwide in spiral towers and can be powered by low tension as well as direct drive.

TwenteSideFlex

TwenteSideFlex is based on the unique design of our TwenteFlex and is designed for use in spiral or oval systems, without a central drum driving the belt. This is our external direct drive solution that may suit your application, system, or workspace better than low tension or inside direct drive.
